LIM G4 - Glass entry aluminium door with decorative panel

SKU
LIM-G4
Rating:
100 % of 100
1  Review Add Your Review
AVAILABLE
£4,240.00

The price includes VAT & shipping

Click here to select the configuration

Doors are manufactured after the order has been placed through the website.
Production time for our doors:
door named LIM (aluminium) - production takes 6 weeks
door named STA (stainless steel) - production takes 4 weeks
door named FARGO (stainless steel) - production takes 7 weeks

Size door with frame:
Width from: 900mm to 1295mm
Height from: 2000mm to 2440mm

Available door colors:
 anthracite, white, black, silver gray, red, blue, yellow, brown, green, walnut, wenge, golden oak, mahogany, custom from RAL palette

You can order this door model in a bigger size. View Pivot G4

Specification:

The multi-point lock FUHR is used for locking. It has many locking and control configurations.
Hinges: the choice of wing or roller hinges and concealed hinges.
Glazing in the door leaf: triple glazing glass
Thickness of polyurethane foam in the leaf: 48 mm
Thermal insulation: Ud = 1.2 W/(m2*K)

The door set includes:

- Aluminium door and the door frame;
- door handle made of stainless steel;
- 3-part roller hinges in the same color as the door;
- Multipoint locking system 855GL : full locking in 7 points, - 2 hooks, - 4 bolts plus upper bolt
- Threshold strip 15 mm height;
- anti-burglary class lock insert with 5 keys.

Full door information

The door is already mounted onto the frame (prehung door), which saves you all the work. The door is completely ready for installation.

The picture showing how to take the measurement. Click here
The installation space between the frame and the wall can be between 5 mm to 20 mm on each side.
Frequently Asked Questions: click here to check

We provide the installation of our front door in England. Installation costs extra and depends on the type of door.

-
+
£4,240.00

The price includes VAT & shipping

Wish List
Email

Profile construction

Specification

  • frame depth: 70 mm / 2.76 inch ,
  • Thermal insulation: Ud = 1.0 W/(m2*K) / R-Value 5.6
  • The multi-point lock FUHR is used for locking
  • Thickness of polyurethane foam in the leaf: 48 mm / 1.9"

The door set includes:

  • Aluminum door and the door frame;
  • door handles made of stainless steel;
  • roller hinges in the same color as the door
  • Multipoint locking system 855GL : full locking in 7 points, - 2 hooks, - 4 bolts plus upper bolt
  • Threshold strip 15 mm / 0.59" height;
  • anti-burglary class lock insert with 5 keys.

Glazing

The glass in our doors are triple-pane windows. All panes are connected with spacer frames. Two of them are covered with Low-E coatings that provide natural light while helping to limit heat gain and thermal energy loss. It is also possible to choose P4 anti-burglary glass or safety glass VSG 33.1

standard glazing package 4th/16Ar/4/16Ar/4th

safety glass 33.1//4//4

P4 anti-burglary

Types of glazing

There is a wide range of glass options. In our offer one will find energy-saving, sound-absorbing, safety, anti-burglary and sunscreen windows. The most popular ones are milk glass, decorative or mirror glass as well as bronze reflex glass.

Colours

Colours can emphasise the shape of aluminium joinery and provide it with individual character and genuine appearance. All aluminium systems offered are available in two colour palettes – RAL and DECORAL.
RAL Basic colour palette.

Fiery red or maybe a delicate blue? The RAL K5 Classic colour palette will allow you to choose the colour of the door perfectly suited to your requirements!



RAL 1003

RAL 2004

RAL 3020

RAL 5002

RAL 6005

RAL 6021

RAL 7016

RAL 7039

RAL 7040

RAL 9016

RAL 9005

RAL 9007

DECORAL woodgrain finish palette

Aluminium doors can also have more traditional, woodlike finishes such as: beech, sweet cherry, golden oak, winchester, mahogany, walnut, dark oak, pine, cherry, wenge.



Golden Oak

Mahogany

Walnut

Wenge

Beech

Roller hinges WR WALA

WR WALA are minimalistic, modern looking, high quality roller hinges. They have been tested and are certified by the German IFT ROSENHEIM. Hinges are protected by patent law and can be adjusted: vertically: -5 to 5mm / -0.2" to 0.2", gap: -2.5 to 2.5 mm / -0.1" to 0.1" , seal pressure: -1.5 to 1.5 mm / -0.05" to 0.05" . When it comes to finish they are available in stainless steel or any colour from the RAL palette (hinges will be painted in the same colour as the door). Depending on the door height there are at least 3 hinges per door leaf/slab.

greenteQ handles

QreenteQ handles are made of anodized aluminum with high resistance to corrosion, weather conditions and scratches.
The INOX version is made of matt stainless steel.
Handle with fixed/rotary bearing and return spring mechanism adapted to the pin square 8 mm / 0.3".
TThe escutcheon/cover plate is 35 mm / 0.14" wide.

T-bar - long vertical handle or normal handle:

Stainless steel door handles are designed for one or two-sided use for external doors.
The innovative mounting system enables quick and easy installation of the door handle. Our offer includes many handrails:




Q45
T-bar at an angle of 45 degrees with a square section of 40 × 40 mm / 1.6"x1.6"
Available in lengths: 1200 / 47.2", 1500 / 59", 1800 mm / 70.9".

P45
T-bar at an angle of 45 degrees with a round cross-section ⌀ 40 mm / 1.6".
Available in lengths: 1200 / 47.2", 1500 / 59", 1800 mm / 70.9".

Z32
Black T-bar with an interesting curve that can also be used for all-glass doors
Available in length 499 mm / 19.6".

Multi-point lock Hook-bolts 855GL type-11

  • steel hooks and pins
  • Three-dimensional locking with integrated hooks and metal pins for optimal security.
  • Pressure adjustment.

Class A insert 6.D.C cylinder with keys

Durability: 100 000 cycles
Security rating: Class 6 the highest
Attack resistance: Class D the highest
Burglar resistance: Class C the highest

Certified, cylindrical, profiled 9-ratchet insert (two rows of latches).
Innovative anti-drill and anti-picking protection.
Inserts resistant to bumping. 5 keys included, key code card.

Write Your Own Review
You're reviewing:LIM G4 - Glass entry aluminium door with decorative panel
Your Rating

The LIM G4 is a striking glass entry aluminium door that masterfully blends contemporary design with robust functionality, making it an ideal choice for both residential and commercial properties seeking to elevate their entrance aesthetics. This door is meticulously crafted to offer a seamless fusion of expansive glass surfaces and decorative paneling, delivering a visually captivating entryway that invites natural light while ensuring privacy, security, and durability.

At the core of the LIM G4’s appeal is its extensive use of high-quality glass, which serves as a centerpiece for modern architectural styles. The door features large glass panels that can be customized with a variety of decorative options, including frosted, textured, patterned, or artistically etched glass. These decorative panels not only enhance the overall visual impact but also provide an element of privacy without compromising the door’s contemporary transparency. Constructed from tempered or laminated safety glass, the panels guarantee superior resistance against impact and breakage, meeting stringent safety standards and offering peace of mind to property owners.

Supporting the elegant glasswork is a precision-engineered aluminium frame that combines strength, corrosion resistance, and sleek aesthetics. The slim, minimalist profiles maximize the glass area, creating a light-filled entrance that complements modern architectural trends. The aluminium frame is treated with a durable powder coating finish that protects against fading, scratching, and harsh weather conditions, ensuring the door’s pristine appearance and low maintenance requirements for years to come. With a broad spectrum of color and finish options available, the LIM G4 can be tailored to perfectly match or accentuate any building facade.

Security and performance are paramount in the LIM G4’s design. The door is fitted with advanced multi-point locking systems and reinforced hardware, delivering exceptional burglary resistance without sacrificing ease of use. The robust construction and secure locking mechanisms work together to safeguard the property while providing smooth, reliable operation. Additionally, the door incorporates thermal break technology and precision seals to enhance energy efficiency by reducing heat transfer and air leakage. This feature contributes to maintaining comfortable indoor temperatures year-round and lowering energy costs.

Beyond its security and aesthetic benefits, the LIM G4 offers excellent acoustic insulation, helping to minimize external noise and create a tranquil interior environment. The door’s smooth pivot or hinge operation, depending on configuration, is supported by high-quality, durable hardware that ensures long-lasting functionality. Versatility is another hallmark of the LIM G4, which can be configured as a single or double door, and paired with complementary side panels or transoms to suit a wide range of architectural styles and entryway dimensions.

Installation of the LIM G4 is designed to be straightforward and precise, thanks to its modular components and adjustable fitting systems. Whether used in new builds or renovation projects, the door integrates seamlessly with existing structures, offering both aesthetic enhancement and functional reliability.

In summary, the LIM G4 glass entry aluminium door with decorative panel is a premium entrance solution that perfectly balances style, security, and performance. Its combination of customizable decorative glass, durable aluminium framing, advanced locking systems, and energy-efficient features makes it an outstanding choice for anyone looking to create a welcoming, secure, and visually stunning entryway. With the LIM G4, you invest in a door that embodies modern elegance, superior craftsmanship, and enduring quality.
