PIVOT M1 - Aluminium pivot door coated with liquid metal

SKU
PIVOT M1
Rating:
100 % of 100
1  Review Add Your Review
AVAILABLE
£10,360.00

The price includes VAT & shipping

Click here to select the configuration

Doors are manufactured after the order has been placed through the website.
Production time for our doors:
door named PIVOT (aluminium) - production takes 6 weeks

Size pivot door with frame:
Width from: 1400mm to 2000mm
Height from: 2000mm to 2940mm

Available door colors:
anthracite, white, black, silver gray, red, blue, yellow, brown, green, walnut, wenge, golden oak, mahogany, custom from RAL palette

You can order this door model in a smaller size. View LIM M1

Technical specifications

Air tightness max. test pressure 4 (600 Pa)
Water tightness 4A (150 Pa)
Wind load resistance C3 (1200 Pa)
Burglar resistance RC2/WK2
Thermal insulation Ud = 0.83 W/K*m2

The door set includes:

- Aluminium pivot door and the door frame;
- the door handle;
- FUHR 835 4-point lock
- low threshold door
- Standard lock insert with 5 keys.

Full door information

The door is already mounted onto the frame (prehung door), which saves you all the work. The door is completely ready for installation.

The picture showing how to take the measurement. Click here
The installation space between the frame and the wall can be between 5 mm to 20 mm on each side.
Frequently Asked Questions: click here to check

We provide the installation of our front door in England. Installation costs extra and depends on the type of door.

-
+
£10,360.00

The price includes VAT & shipping

Wish List
Email
We found other products you might like!

Technical specifications:

  • frame depth door: 78 mm / 3.1",
  • Depth Vent: 78 mm / 3.1"
  • Air tightness: Class 4 (600Pa)
  • Wind load resistance: Class C3 (1200Pa)
  • Water tightness: Class 4A (150Pa)
  • Opening & closing resistance: Class 5
  • standard glazing package 4th/16Ar/4/16Ar/4th [Ug=0,6]*
  • Burglar resistance: RC2
  • Thermal insulation: Ud = 0.83 W/K*m2 / R-Value 6.8

The door set includes:

  • Aluminium pivot door and the door frame;
  • the door handle;
  • FUHR 833 3-point lock
  • low threshold door
  • standard lock insert with 5 keys.
Pivot door in full glass version

Pivot door with an aluminum overlay panel

Glazing

The glass in our doors are triple-pane windows. All panes are connected with spacer frames. Two of them are covered with Low-E coatings that provide natural light while helping to limit heat gain and thermal energy loss. It is also possible to choose P4 anti-burglary glass or safety glass VSG 33.1

standard glazing package 4th/16Ar/4/16Ar/4th

safety glass 33.1//4//4

P4 anti-burglary

Types of glazing

There is a wide range of glass options. In our offer one will find energy-saving, sound-absorbing, safety, anti-burglary and sunscreen windows. The most popular ones are milk glass, decorative or mirror glass as well as bronze reflex glass.

Colours

Colours can emphasise the shape of aluminium joinery and provide it with individual character and genuine appearance. All aluminium systems offered are available in two colour palettes – RAL and DECORAL.
RAL Basic colour palette.

Fiery red or maybe a delicate blue? The RAL K5 Classic colour palette will allow you to choose the colour of the door perfectly suited to your requirements!



RAL 1003

RAL 2004

RAL 3020

RAL 5002

RAL 6005

RAL 6021

RAL 7016

RAL 7039

RAL 7040

RAL 9016

RAL 9005

RAL 9007

Touch line handles

Touch line handles are made of the highest quality materials. They are available in anodized versions (covered with a layer of aluminum oxide) and powder coated in the entire range of the RAL palette (400 + colors).

Sublime, timeless design makes these elegant handles emphasize the appearance of each door.

T-bar - long vertical handle or normal handle:

Stainless steel door handles are designed for one or two-sided use for external doors.
The innovative mounting system enables quick and easy installation of the door handle. Our offer includes many handrails:




Q10
T-bar with a square section of 40×40 mm / 1.6"x1.6".
Available in lengths: 1200 / 47.2", 1600 / 63", 1800 mm / 70.9".

Q45
T-bar at an angle of 45 degrees with a square section of 40 × 40 mm / 1.6"x1.6"
Available in lengths: 1200 / 47.2", 1600 / 63", 1800 mm / 70.9".

P10
T-bar with a round cross-section ⌀ 40 mm / 1.6" .
Available in lengths: 1200 / 47.2", 1600 / 63", 1800 mm / 70.9"

P45
T-bar at an angle of 45 degrees with a round cross-section ⌀ 40 mm / 1.6".
Available in lengths: 1200 / 47.2", 1600 / 63", 1800 mm / 70.9".

Z18
Black, designer handle.
Available in length 480 mm / 18.9".

Z20
Black T-bar with an interesting design
Available in length 498 mm / 19.6".

Z32
Black T-bar with an interesting curve that can also be used for all-glass doors
Available in length 499 mm / 19.6".

Z24
Black, oval handle
Width 450 mm/ 17.7"

Z52
T-bar round z52 copper
⌀ 198 mm / 7.8"

Z53
T-bar round z53 silvershine
⌀ 198 mm / 7.8"

Z54
T-bar round z54 slivergalaxy
⌀ 198 mm / 7.8"

Recessed
T-bar recessed
Available in lengths: 1200 mm / 47.2" and 1800 mm / 70.9"

Multipoint locking system Fuhr 835

Automatic multipoint locking system with a deadlocking latch.

Fuhr lock is the excellent locking system that guarantees comfort as well as security. The lock function ensures reliable, automatic locking and protection against uninvited guests. All you have to do is pull the door closed.

After closing the door, our three-point locking system protects against door warping, offering long-lasting seal tightness and a thermal efficiency.



The most important features:

Increased security – due to automatic locking there is no need for conventional locking with using a key.

Convenient opening – Effortless key operation thanks to two-stage opening sequence from the outside or using the lever handle from the inside.

Increased heat insulation – The multipoint locking system prevents the door from warping to ensure consistent seal tightness around the whole door leaf/slab.

Reliability and durability – long service life is guaranteed and has been tested with over 200,000 cycles.



Locking the lock:
  • After closing the door, the latch in the main lock and additional bolts automatically lock the door.
  • A single turn of the key causes the bolt of the main lock to be activated.
Unlocking the lock:
  • Turning the key once withdraws both lock and bolts. Pressing the handle down causes the latch to be automatically released and allows to open the door.



Class A insert 6.D.C cylinder with keys

Durability: 100 000 cycles
Security rating: Class 6 the highest
Attack resistance: Class D the highest
Burglar resistance: Class C the highest

Certified, cylindrical, profiled 9-ratchet insert (two rows of latches). Innovative anti-drill and anti-picking protection. Inserts resistant to bumping. 5 keys included, key code card.

Write Your Own Review
You're reviewing:PIVOT M1 - Aluminium pivot door coated with liquid metal
Your Rating

The PIVOT M1 Aluminum Pivot Door Coated with Liquid Metal is a groundbreaking architectural masterpiece that perfectly marries cutting-edge technology with sophisticated design to deliver an entry solution unlike any other. Crafted for modern spaces that value innovation, durability, and striking aesthetics, this premium pivot door stands out as a symbol of luxury and engineering excellence, making it the perfect choice for upscale residential, commercial, and institutional projects seeking to make a bold and enduring statement.

At its core, the PIVOT M1 features a high-performance aluminum frame renowned for its exceptional strength, lightweight nature, and inherent resistance to corrosion and environmental wear. Unlike conventional hinged doors, the PIVOT M1 operates on an advanced pivot system that allows the door to rotate smoothly around a fixed central axis. This innovative mechanism not only enables the installation of larger and heavier door panels but also creates a dramatic, sweeping motion that elevates the user experience and enhances the architectural flow of any space. The pivot design offers a minimalist yet powerful visual impact, providing an inviting entrance that seamlessly blends form and function.

What truly distinguishes the PIVOT M1 is its exclusive liquid metal coating—a revolutionary finishing process that transforms the aluminum surface into a lustrous, mirror-like facade with a rich metallic depth. This state-of-the-art coating is more than just visually stunning; it imparts extraordinary durability by forming an ultra-hard, protective layer that resists scratches, fading, and corrosion, ensuring that the door maintains its pristine appearance even in the harshest weather conditions. The liquid metal finish delivers a dynamic interplay of light and reflections, adding a captivating dimension to the door’s presence and making it a true centerpiece in any architectural setting.

Beyond its striking aesthetics, the PIVOT M1 is engineered for superior performance and sustainability. It incorporates advanced thermal break technology within the aluminum frame, significantly reducing heat transfer and enhancing energy efficiency. When combined with premium double or triple-glazed low-emissivity glass panels, the door offers excellent insulation properties, helping to maintain comfortable indoor temperatures while minimizing energy costs. This focus on thermal performance makes the PIVOT M1 an environmentally responsible choice that contributes to green building standards without compromising style.

Security is a paramount consideration in the design of the PIVOT M1. The door is fortified with heavy-duty pivot hardware and an integrated multi-point locking system that provides robust protection against forced entry. Additionally, it can be outfitted with high-strength laminated or tempered safety glass options, enhancing both security and safety without detracting from the door’s sleek, modern aesthetic. These features ensure peace of mind for property owners while maintaining the door’s elegant profile.

Customization is a key advantage of the PIVOT M1, offering a wide range of options to suit diverse architectural styles and project requirements. From various sizes and configurations to multiple hardware finishes and glass types, this pivot door can be tailored to create a bespoke entrance solution that perfectly aligns with the design vision. Whether installed as a grand main entrance, a sophisticated interior partition, or a statement feature in commercial environments such as galleries, offices, or luxury retail spaces, the PIVOT M1 brings unparalleled style and functionality.

Installation is supported by expert technical guidance to ensure precision alignment and smooth, reliable operation. The carefully engineered components are designed for long-term durability and ease of maintenance, making the PIVOT M1 not only a stunning visual centerpiece but also a practical, high-performance architectural element.

In summary, the PIVOT M1 Aluminum Pivot Door Coated with Liquid Metal redefines the concept of premium pivot doors by combining innovative pivot mechanics, robust aluminum construction, a stunning liquid metal finish, exceptional energy efficiency, and enhanced security features. It is the ultimate choice for those seeking a luxurious, durable, and visually captivating pivot door that elevates any architectural project to new heights of elegance and performance.
